Motor
- All in one package for mobile project
- Chasis, gear motor and screws included
- Able to mount other modules or accessories
RM19.50
- Driven by ULN2003 chip
- Operating Voltage 5V
- 2 phase(unipolar) mode
- 4 phase(bipolar) mode
- For basic micro stepping application
RM12.00
- Metal-geared analog servo
- Delivers extra-high torque
- Supply Voltage: 6.0V
RM80.00
- Operating Voltage: 3-6VDC
- Rated Current: 0.35-0.4A
- Shaft diameter: 2mm
- Shaft Length: ~8mm
- Size: 20mm x 15mm x 25mm
- RPM at 3V : 17000-18000rpm
RM2.00
- Control motors speed and direction
- Logical voltage: 5V
- Drive current: 2A
- Max power: 25W
- Has onboard switch button to control power supply
RM10.50
- Lightweight with high output power
- 180 degrees (90 in each direction)
- Fit in small places
- Operating voltage: 4.8 V (~5V)
RM7.00
- Bipolar stepper motor with heatsink
- Operating Volt : 8V-25V
- Rated Current 2A
- Crossover-current protection
RM5.10
- Motor type : 3 pole
- Operating voltage 4.8V-7.2V
- Digital Modulation (PWM control)
- 225 Degree
RM25.00
Motor Specification Required:
- Two Terminals DC Brush Motor
- Operating Voltage (DC): 5V to 30V
- Rated Current: less than 30A (<30A)
- Peak Current: less than 80A (<30A)
Features:
- Bi-directional control for 1 brushed DC motor, single channel
- Motor Voltage: 5V to 30VDC
- Maximum Output Current: 80A peak (1 second), 30A continuous
- Reverse polarity protection for Vmotor
- 3.3V and 5V logic level input, compatible with: 5V Arduino boards such as Arduino UNO, Maker UNO, CT-UNO, Arduino Mega2650 or 3.3V Arduino board such as Arduino Zero or Raspberry Pi boards which include 3B, 3B+, 3A+, Zero, Zero W, Zero WH
- Full NMOS H-Bridge for higher efficiency and no heat sink is required
- Brakes the motor when PWM pin is low (logic low)
- Speed control PWM frequency up to 20KHz (Actual output frequency is same as input frequency when external PWM is selected)
- Onboard PWM generator with switches and potentiometer for standalone operation
- Support both locked-antiphase and sign-magnitude for external PWM operation. Note: PWM is not "RC PWM"
- Dimension: 78.74mm x 93.98mm
RM105.00
- Origin: China
- Metal gears
- Operating Voltage: 4.8 - 6VDC
- Speed at 6.0V(no load): 0.14sec/60°
- Torque at 6.0V: 17 kg.cm (~1.667 N.m)
- Rotation angle: 180 degree
- Size: 40.7x20.5x39.5mm
- Weight: 60g
RM42.60
- Model Number: 17HS19-2004S1
- Motor Type: Bipolar Stepper
- Step Angle: 1.8 deg
- Step Accuracy: 5%
- Holding Torque: 59Ncm(84oz.in)
- Rated Current/phase: 2.0A
- Voltage: 2.8V
- Phase Resistance: 1.4ohms
- Inductance: 3.0mH ± 20%(1KHz)
- Weight: 400g
RM50.00
- Operating Voltage: 24 VDC
- Rated Speed: 2600RPM
- Rated Torque: 1.2N.m
- Rated Current: 18Amp
- Rated Output Power: 350W
- Motor Diameter: 101mm
- Motor dimensions (w x l x h): 110mm x 110mm x 109.5mm
- Weight: ~ 2.364kg
RM150.00
RM65.00
- Supply Voltage: Up to 36 V(depends on driver)
- Compact Design
- 4-Axis support (X, Y, Z , A-Can duplicate X,Y,Z or do a full 4th axis with custom firmware using pins A4 and A3)
- 2 x End stops for each axis (6 in total) + one Probe
- PWM Spindle and direction pin
- Coolant enable output
RM11.50
- Voltage Input: 9 to 42VDC
- Input Current: 0~5A
- Output Current: 0.5-4.0A
- Max Power: 160W
- Micro Step: 1, 2/A, 2/B, 4, 8, 16, 32
- Weight: 0.2 kg
- Dimension: 9.6 x 5.6 x 3.3 cm
RM45.00
